| Item | 1000BASE SFP |
| Compatible | SFP-GE-LX-SM1310 |
| Part Status | Active |
| Form Factor | SFP |
| Max Data Rate | 1.25Gbps |
| Wavelength | 1310nm |
| Max Cable Distance | 10Km |
| Media | SMF |
| Connector | Duplex LC |
| Optical Component | FP/PIN |
| TX Power | -9.5~-3dBm |
| Receiver Sensitivity | <-20dBm |
| Receiver Overload | -3dBm |
| Power Consumption | ≤1W |
| Extinction Ratio | >9dB |
| DDM/DOM | Supported |
| Commercial Temperature | 0 to 70°C (32 to 158°F) |
| Protocols | IEEE 802.3ah-2004, IEEE 802.3z, SFF-8472, SFP MSA Compliant |
| Warranty | 5 Years |
With over 10 years of experience in chips and modules, we integrate high speeds, compact sizes, and power efficiency into every solution. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, WDM, and data communication networks.
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, ROSH, REACH, CE, and UL. Our facility owns advanced manufacturing and test equipment to ensure top-tier performance.
Established in 1997, our production capacity reaches 3000K units per month, allowing for rapid delivery. We provide a full series of optical modules for cloud computing, wireless access, and ultra-broadband networks worldwide.
