Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4

1 / 5

Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4

Send Inquiry

Product Description

Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4

Tyco Part Number	1116173-4
LINK-PP Part Number	LPJE101AHNL
Application-LAN	ETHERNET(NON POE)
AutomDX	YES
Package Height (Inches/mm)	0.516/13.10
Package Length (Inches/mm)	0.620/15.75
Package Width (Inches/mm)	0.640/16.26
Configuration TX/RX	T,C
Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Cores Per Port	-
Diodes	No
Latch	Up
LED Option	Green/Yellow LEDS
Number of Ports	1X1
PCB Mount Angle	SIDE ENTRY
PCB Retaining Post	T POST
Pin Type	THT SOLDER
RoHS Compliant	YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Shield EMI Tabs	WITH
Temperature	-40 TO 85°C
Turns Ratio RX	1CT:1
Turns Ratio TX	1CT:1

Why Choose Us

World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers

📜 Professional Certification

ISO 9001:2008
UL Certification
Reach Certification
RoHS Compliance
Active Environmental Policy

🛡️ 100% Guarantee Quality

Manufactured Under Strict Controls
100% Tested (Not Just Batch Tested)
OEM Of TE (Tyco) For 9 Years
Preferred Supplier Of TI (Texas Instruments)
Quality Guarantee: 6 Years

💰 Competitive Price & Service

More Competitive Price Than Pulse, Tyco, Halo, Wurth
Delivery Time: 2-3 Weeks After Orders
Free Samples Are Available
90% Off Shipping Cost By DHL, UPS, FEDEX Or TNT

🏢 Corporate Policy

The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction Through Continuous Improvements In Quality, Delivery And Service. LINK-PP Is Committed To And Expects Quality Performance From Every Employee. The Company Standard Is Defect-Free Products And Services.

• LINK-PP Is The Preferred Supplier Of TI Samsung Cisco Siemens ...

Welcome To Visit The TI Website. You Will Look At Our Logo “LINK-PP” On BeagleBone Board

Frequently Asked Questions

1. What is the application for this RJ45 Modular Jack? This connector is specifically designed for Networking and LAN applications, supporting standard Ethernet (Non-PoE) connections.

2. What are the LED color options for the 1116173-4 part? This model comes with Green and Yellow LEDs to indicate network status and activity.

3. Is this RJ45 connector RoHS compliant? Yes, it is RoHS compliant (RoHS-5) with lead-in-solder exemption, meeting international environmental standards.

4. What is the operating temperature range for this component? The product is built to perform reliably in temperatures ranging from -40°C to +85°C.

5. Can I get samples for testing before placing a bulk order? Yes, free samples are available for customer evaluation and design requirements.

6. What is the standard lead time for delivery? Typically, the delivery time is 2-3 weeks after the order is confirmed, depending on the order volume.
